Hitec RCD

Servo D-625 MW

Hitec servo D625MW

Meer details

Hitec RCD

MPX116625

Op voorraad Op voorraad in onze winkel. Levering binnen 24/48u.

 Verzendkosten vanaf 4.99€
of gratis afhaling in de winkel. .

39,99 €

Meer informatie

Fast premium digital servo of the 20 mm class

The D625MW, the fast variant of D645MW, provides Thanks D series Technolgie with 32-bit MCU (Master Control Unit) and 12-bit ADC (analog-to-digital converter) currently the highest in the market available resolution servo travel.
Finest response and perfect positioning accuracy can be realized hereby.
Wide-Voltage servos can directly 2-cell Lithium-based batteries (LiFe / Lilo / LiPo) with a nominal voltage of 4.8 - 8.4 V to operate.
The D625MW Digital servo is fully programmable and offers good durability, thanks to its rugged metal gear and with two ball bearings on the output shaft. It is particularly suitable when low clearance and high positional accuracy are important.
The long life and the uniquely designed gearbox make it a most reliable and efficient servos on the market.

Belangrijke kenmerken

Features:
• programmable
• quickly
• metal gears
• 2 ball bearing MR106
• 25 splines for servo horn
• Long Life potentiometer


Programmable Features:
• setting the end point (0 ° -180 °), neutral (standard ± 60 °)
(• adjusting the direction of rotation clockwise / anti-clockwise)
• setting the dead zone
• adjusting the speed (default 100%))
• setting soft Start (default 20%)
• setting the fail-safe function
• adjusting the overload protection (from standard)
• Factory settings restored

Specificaties

  • Width : 20 mm
  • height : 38 mm
  • length : 41 mm
  • Weight : 0.055 Kg
  • servo Type: Standard
  • Features: Wide Voltage Digital
  • Engine type servos: coreless
  • Transmission: metal
  • operating voltage in V: 4.8 to 8.4 V
  • operating time s / 60 ° at 4.8 volts: 0.2
  • setting time s / 60 ° at 6.0 volts: 0.15
  • actuating time s / 60 ° at 7.4 volts: 0.13
  • torque kgcm in at 4.8 volts: 6
  • torque in at 6.0 kgcm voltage: 9
  • torque in kgcm at 7.4 volts: 10
  • teeth: 25T
  • Bearings: Yes
  • Waterproof: No
  • flight Yes
  • Recommendation Heli: Yes
  • Recommended Car: Yes
  • Recommended boat: Yes

Productgegevens

  • Fabrikant : Hitec RCD

Samenstelling van de kit

  • 1x 20mm servo D625MW
  • 1x Servohebel HD-LS25 mounted
  • 1x servo lever (disc) HD-OS25
  • 1x servo lever (cross) HD-X25
  • 1x Servohebel HD-IM25
  • 1x servo Befestigungsset, screws, grommets, rubber
  • 1x Allen screw M3x7
