Servo Brushless HV - High torque i-BUS2 75.0kg/0.10sec @8,4V

Usage : 1/10 Crawler, 1/8 Crawler, 1/8 Nitro Buggy, 1/8 Electric Buggy, 1/5 Nitro Touring, 1/5 Nitro Buggy

The latest generation of SRT  servos provides you with the performance you need for any scale vehicle\ Air Plane\Boat\Robot application are standard size servos for High-Voltage applications up to 8.4V, feature all metal case construction for the ultimate performance.

All of SRT servos  are available to be customized for easy installation by OEM order.

• Superior Holding Torque
• Incredible efficiency and low power consumption
• Standard dimension make it perfect for vehicles that can benefit from a high quality servo
• CNC Machined aluminum case for exceptional cooling
• Programmable High torque Brushless servo
• Supporting SXR, SUR, SR, SFR multiple ultra high speed modes
• 25T output shaft
• 2 μsec Dead Band
• 1-Year Limited Warranty

• Type: Digital
• Bearing: Dual
• Motor Type: Brushless
• Gear Type: Metal
• Gear Material: Steel
• control system: pulse width control
• working frequence: 1520μs / 330hz
• operating voltage: dc6.0-8.4v
• operating temperature range: -10 to + 60 degree
• operating speed (6.0v): 0.15 sec/60 degrees at no load
• operating speed (7.4v): 0.11 sec/60 degrees at no load
• operating speed (8.4v): 0.10 sec/60 degrees at no load
• stall torque (6.0v): 55.0kg.cm (763.8 oz/in)
• stall torque (7.4v): 65.0kg.cm (902.7 oz/in)
• stall torque (8.4v): 75.0kg.cm (1041.6 oz/in)
• potentiometer drive: direct drive
• dimensions: 40.0 x 20.0 x 39.2 mm /1.57 x 0.79 x 1.54 in
• weight: 82.0g (2.89 oz)
• connector wire length: jr 300 mm
